Description

Technical Parameters

Ruite Submersible Slurry Pump is a centrifugal pump for abrasive slurry transfer in mining, mineral processing, dredging and industrial operations. The fully submerged arrangement places the pumping unit directly at the slurry collection point.

Performance Data

Item	Specification
Pump Type	Submersible centrifugal slurry pump
Operation	Fully submerged
Maximum Submergence Depth	Up to 200 m
Wet-End Material	High-chrome alloy cast iron
Agitator	Optional inlet-mounted agitator
Motor Sealing	Double-end mechanical seal
Motor Protection	Waterproof motor, overload protection
Motor Cooling	Cooling system available for high-power motors
Pump Arrangement	Pump and motor integrated as one submerged unit

Submerged Pumping

The pump and motor form one submerged unit installed directly in the pit, tank or slurry collection point, eliminating a separate suction-side pump. The unit is lifted vertically for maintenance.

Solids Handling

High-chrome alloy wet-end components provide wear resistance against abrasive solids. Impeller, casing or liner and wear plates are replaceable, keeping wear components separate from the complete pump assembly.

Agitator System

An optional inlet-mounted agitator disturbs settled solids at the suction point before pumping. It is particularly relevant to bottom sediment in pits, ponds and tanks.

Motor Protection

The motor protection arrangement combines waterproof construction, overload protection and double-end mechanical sealing. High-power motor configurations include additional cooling for heat control during submerged operation.

Quality Inspection

Ruite inspects materials, dimensions, machining, assembly and rotating-component balance before shipment. Inspection records and agreed technical documents are available for project orders, with third-party inspection available before shipment.

Purchasing Terms

Item	Standard Term
MOQ	1 set
Lead Time	15–30 working days
Payment	T/T; other terms by agreement
Packaging	Export wooden case or reinforced export packing

FAQ

Q: Are spare parts available separately?

A: Yes. Impellers, casings or liners, wear plates, agitators and seal components are available separately.

Q: Are repeat orders based on previous specifications?

A: Yes. Previous production records provide the reference for recurring pump and spare-parts orders.

Q: Can third-party inspection be included?

A: Yes. Inspection scope and acceptance requirements are agreed before shipment.

Q: Are project orders available in batches?

A: Yes. Production and shipment can be arranged in agreed batches for project requirements.

Q: What technical documents are supplied with project orders?

A: Product drawings, technical specifications and inspection documents are available as part of the project documentation.

Q: How are older pump parts identified?

A: Existing part numbers, drawings and component dimensions provide the primary identification references.

Q: How are modified pump configurations handled?

A: The current installed configuration is checked against the available component information before replacement supply.

Q: What packing is available for export shipments?

A: Export wooden cases or reinforced export packing are available for international transportation.

Q: Is the agitator available as a replacement part?

A: Yes. The agitator is supplied separately for replacement requirements.

Q: Is the same pump specification available for repeat procurement?

A: Repeat supply follows the retained technical and production records from the previous order.
